Just how to choose a suitable compression proportion for biomass pellet mill? How is the compression proportion of the biomass gas pellet equipment calculated? The compression proportion supplied by the biomass pellet mill producer is normally calculated according to the details gravity of the local product of the manufacturer. Just how does the customer choose the proper compression ratio?

Related post: biomass pellet machine price

1.Just how to pick a ideal compression proportion?
The mold compression proportion of the biomass pellet mill is determined according to the raw product, so allow’s cite a few basic timbers. The compression ratio of poplar is 1:6, the compression ratio of ache is 1:7, the compression proportion of hard miscellaneous timber is 1:5, the compression proportion of damaged shavings is 1:5.5, and the compression ratio of corn stalk is 1:8. Going by these simple numbers, the compression proportion of various basic materials is different.

The more challenging the raw product, the smaller sized the compression proportion, and also the even more fluffy the raw material, the greater the compression proportion. The raw material includes a great deal of fiber, as well as the product with a lot of fiber is simple to create. Then allow’s speak about the compression ratio of poplar timber of 1:6. What do the 1 and also 6 in the numbers represent? There are 6mm, 8mm, and 10mm straight for each little opening of the biomass pellet mill of the ring die, as well as this 1 stands for the diameter of the hole of each small opening.

Related post: https://www.pellet-richi.com/wood-pellet-machine/biomass-pellet-mill.html

If the size of the ring die opening is 8mm, then this 1 stands for 8, and also 6 stands for the efficient aperture. The efficient aperture is equal to the size of the hole increased by the efficient aperture length, that is, 6 * 8= 48. That is, 8:48.8:48 is simplified to 1:6, as well as 1:6 is the compression proportion of poplar, which is converted this way.

The top quality of the biomass pellet mill depends on the compression proportion of the ring die, but if the client The molding rate of your production of timber pellets is not really high, so you can properly decrease the compression ratio, which can not only boost the output, but additionally reduce the life span of the mold and mildew and the pressure roller. So exactly how to choose the ideal mold:

Related post: biomass pellet plant manufacturers

First of all, on the premise of choosing a great biomass pellet mill ring die, the proper die hole form, opening proportion and compression ratio (compression proportion = reliable length of the die hole size) must be picked according to the certain gravity of the manufacturing material. On the premise of making certain the toughness of the ring die, try to enhance the opening price of the ring die. For some kinds of materials, under the problem of making certain a affordable compression proportion, the ring die is as well slim, to make sure that the stamina of the ring die is not enough, and also surges might occur throughout manufacturing. At this time, the thickness of the ring die and also the decompression hole should be raised under the property of guaranteeing the effective size of the die opening.

The ring die compression proportion describes the ratio of the reliable size of the ring die hole to the minimal diameter of the ring die hole, which is an index reflecting the extrusion strength of wood pellets. The greater the compression proportion, the stronger the extruded timber pellets.

Related post: straw pellet machine for sale

For the compression proportion of the biomass pellet making maker ring die of the straight opening, the efficient size of the ring die hole is the total density of the ring die, and the minimum size is the diameter of the die opening itself; for the release stepped opening as well as the external conical opening, the die The efficient length of the hole is the complete thickness of the ring die minus the size of the launch opening or the length of the external tapered hole, and the hole size of the little size area is the hole diameter for calculating the compression ratio; for the compressed stepped opening as well as the inner conical opening, this situation is unique.

Usually, the density of the whole ring die is utilized as the efficient size of the die opening, and the minimum diameter is the diameter of the little diameter section. Naturally, the meaning of the ring die compression proportion calculated in this way is different from the initial 2 cases.

Roughness is likewise an essential sign to gauge the high quality of the biomass pellet mill machine ring die. Under the same compression ratio, the bigger the roughness value, the higher the extrusion resistance of the timber pellets, and also the harder it is to release. Extreme roughness additionally affects the quality of the pellet surface area. A suitable roughness value need to be in between 0.8 and 1.6.

Related post: Peanut Shell Pellet Mill

2. What is the need of establishing biomass power?

The advancement of biomass energy is conducive to boosting the well-being as well as quality of life of the more than 500 million country people throughout the country, advertising the mix of growing and reproducing and the revitalization of country ecology, lowering air contamination and fossil energy intake, and promoting nationwide power safety and security as well as low-carbon eco-friendly advancement.

The core of the power transformation is the transition from fossil power to a low-carbon power system dominated by renewable resource. Vigorously promoting biomass energy in backwoods can curb unreasonable country energy intake, successfully boost the energy usage framework of rural homeowners, lower contaminants and also greenhouse gas exhausts brought on by fossil energy usage in rural areas, and add to the establishment of a prosperous culture that satisfies the requirements of rural areas in an overall method.

3.The need for biomass pellet mill boosts
With the boosting cost of food, the plants that were straight thrown out can be reprocessed by biomass pellet mill to come to be the feed needed for farming. In addition, sawdust and straw processed by sawdust pellet machine or straw pellet device The pellets can be sent straight to power plants to replace coal and also made use of as a brand-new energy source. This significantly lowers expenses and also is acknowledged by more and more consumers.

The three primary power sources used by people today are oil, natural gas as well as coal, all of which are non-renewable power sources. According to specialists’ predictions, if the demand for energy at the existing financial development speed is met, these three power sources that can be exploited and also made use of in the earth, will certainly be tired in 40 years, 60 years and also 200 years respectively, the advancement as well as application of brand-new power has become an urgent issue in human advancement. Given that the global oil dilemma occurred in the 1970s, the growth and use of renewable resource has attracted more and more attention. Bioenergy is an essential renewable resource. In the present globe power intake, bioenergy accounts for 14% of the world’s overall power usage, 2nd just to In oil, gas as well as coal, it ranks fourth.

Related post: Olive Pomace Pellet Mill

Straw timber biomass pellet mill modern technology is suitable for promo and application in woodland locations and farming locations abundant in biomass sources, and also can likewise be made use of to treat crop straw, wood waste from furnishings factories as well as timber processing manufacturing facilities.

（ 1 ） The calorific value of straw pellets and sawdust pellets is large, the calorific value is about 3900 ~ 4800 kcal/kg, as well as the calorific worth after carbonization is as high as 7000-8000 kcal/kg.
（ 2 ） The fuel of straw pellets and also sawdust pellets has high purity and also does not include various other impurities that do not produce warm. Its carbon web content is 75-85%, ash material is 3-6%, water material is 1-3%, and it does not consist of coal gangue. Stones and various other impurities that do not produce heat but take in warm will directly minimize prices for enterprises.
（ 3 ） The fuel of straw pellets and wood pellets does not have sulfur as well as phosphorus, as well as does not corrode the central heating boiler, which can prolong the life span of the central heating boiler, and also the business will profit a great deal.
（ 4 ） Since straw pellets and timber pellets do not contain sulfur as well as phosphorus, they do not create sulfur dioxide as well as phosphorus pentoxide during burning, so they will not create acid rain, pollute the environment, or pollute the atmosphere.
（ 5 ） Straw pellets and wood pellets are clean and also hygienic, easy to feed, decrease the labor intensity of workers, considerably boost the labor environment, and also business will reduce the price of labor.
（ 6 ） After melting straw pellets and also timber pellets, there is very little ash ballast, which significantly minimizes the site for stacking coal slag and minimizes the expense of slag elimination.
（ 7 ） The ashes after shedding straw pellets as well as wood pellets are high-grade organic potash fertilizers with very high grades, which can be recycled to produce earnings.

Related post:sugarcane bagasse pellet mill

As a brand-new kind of pellet fuel, straw pellets and wood pellets have won vast acknowledgment for their one-of-a-kind benefits. Compared with traditional fuels, it not only has financial benefits yet likewise ecological benefits, and completely fulfills the demands of lasting development.

With the promotion of environmental management as well as the reduction of raw materials in lots of countries, biomass pellet mills, sawdust pellet devices and also straw pellet devices have developed by jumps and also bounds. What about the prospects of biomass pellet mills? What are the advantages? RICHI Equipment Co., Ltd. will introduce to you.
