The major feature of the fish feed floating pellet making device is to directly extrude puffed food. Normally, grains, potatoes or beans are made use of as the primary resources.
Related post: Pellet Extruder
After being extruded by thefloating fish feed making device, under the problems of high temperature as well as high pressure, the product is puffed by utilizing the pressure distinction inside as well as outside the equipment
The straight extrusion type blew food typically does not include lead, as well as currently the fish feed drifting pellet making machine is commonly utilized in the food sector. So just how much do you find out about the drifting fish feed extruder? The fish feed drifting pellet making maker has a set of screws and a screw sleeve, which have the functions of blending as well as massaging.
After the raw product enters the squeezing out tooth cavity, the material undergoes extrusion, friction and also shearing in between the screw sleeves, as well as the inner pressure remains to rise, approximately 4Mpa, as well as the temperature level continues to increase, as much as 140 ℃.
Within 3-7s, the temperature and also pressure of fish feed floating pellet making device surge sharply, as well as the cells structure of the material adjustments, which additionally gelatinizes the starch, denatures the protein, ruins the unrefined fiber, as well as kills damaging microorganisms such as Salmonella.
The high-temperature as well as high-pressure product comes out of the discharge port, and also its pressure is suddenly released in an split second, and the dampness is partially blinked.
1. The structure of drifting pellet making maker.
The feeder is to ensure consistent as well as secure feeding, as well as readjust the feeding amount according to the rated current worth of the electric motor of fish feed drifting pellet making maker. Normally, an electro-magnetic speed-regulating electric motor or a frequency converter is used to readjust the rate, and the feeding quantity of the feeder is transformed.
Related post: https://www.richipelletmachine.com/fish-feed-extruder-machine/
Expansion tooth cavity of fish feed floating pellet making machine is made up of screw, screw sleeve, layout, card bone and so on. The screw and also screw sleeve are integrated in sections, the compression level can be adjusted according to the type and demands of the extruded feed, as well as the extruded level of the extruded feed can be changed;
The fish feed drifting pellet making machine is separated into three areas in terms of collapse degree according to function and position:
① Feeding area: This area of floating fish feed machine has a large screw pitch, and also primarily communicates and presses the product to ensure that the material loads the spiral groove;
② Compression area: The screw groove of this area changes from deep to superficial along the product relocating instructions to compress the product;
③ Extrusion area: the screw groove is shallower, the pitch gradually becomes smaller, the extrusion force can reach 3.0-10Mpa, and also the temperature level can get to 120-150 levels Celsius. This section has the highest possible pressure and highest possible temperature level, so the wear of the screw and also screw sleeve is additionally the most major.
The electrical outlet of the extrusion area is a design template, the shape of the theme is developed with different die openings according to the requirements of different feeds, the material is extruded from the die hole of the template and enters the atmosphere, the pressure as well as temperature drop dramatically, and its quantity expands swiftly, the water rapidly vaporizes, dehydrates and strengthens to become an extruded material.
2. Fixing of fish feed floating pellet making maker
Transform the fish feed floating pellet making device on-site control button to the quit state throughout upkeep;
The within and beyond the fish feed drifting pellet making device needs to be cleaned after each change, particularly the material ought to not be preserved in the puffing chamber, so as to avoid it being challenging to tidy up after cooling and also agglomeration;
The large wheel of the primary shaft of the puffing chamber ought to be cleaned often, and not excessive dirt, otherwise the sheave will be out of balance as well as the puffing chamber will shake;
The major bearing of the expansion chamber is lubed with lubricating oil, and also the bearing of the fish feed floating pellet making maker conditioner and also its transmission tool and also various other bearing components are lubricated with grease;
The major bearing has to be changed with brand-new oil consistently. After 250 hours of job, all brand-new oil should be replaced;
Other bearing parts, every two days of job, oil is infused when;
The chain transmission device on the vapor conditioner should be lubricated frequently;
The oil in the reducer of fish feed floating pellet making machine needs to be controlled at the adjusted oil level, as well as the new oil needs to be replaced after 250 hours of procedure;
When removing the screw head, do not knock it hard;
Constantly maintain the fish feed floating pellet making equipment as well as its surroundings clean.
